ETC8M

The ETC8M is a Mil Spec 8 Channel Thermocouple to CAN device using the Motorsport proven Deutsch Autosport connector(Red).

The enclosure is made from billet 6061 aluminium and is water proof to allow for implementation in extreme environments.

Range

• -200 to 1350 DegC
• Sampling rate 500 Hz
• Internal or External Cold Junction Correction

Communications

• CAN Baud Rate: 250kBaud, 500kBaud or 1Mbaud Auto Detect
• CAN Transmit Rate Adjustable: 100Hz/200Hz/500 Hz

Powwer Supply

• Operating Voltage: 7.0 to 22.0 Volts DC
• Operating Current 50mA at 14.0V
• Reverse Battery Protection
• Battery Transient Protection

Internal

• 64MHz 16-bit Automotive Processor
• x8 K-Type Thermocouple Inputs.

Operationg Temperature

• Operating Temperature Range: -30 to 85°C (-22 to 185°F)
